Replace Side-Drive PCP

No more pulley-and-gear-reducer setups. Boremax runs coaxial direct drive with far fewer mechanical interfaces to fail. Eliminate belt, gearbox, and alignment maintenance with integrated controller management and controlled deceleration.

Feature Side-Drive PCP Boremax Direct Drive
Mechanical Setup Motor plus belt or gearbox Coaxial direct-drive motor (no belts/gearbox)
Moving Parts Belt, gearbox, alignment & wear points Designed to drastically reduce routine wear components
Braking & Safety Configuration-dependent mechanical braking Patented 0.5s magnetic-powder brake (≤20 rpm limit)
Energy Use Mechanical loss in belts and speed reducers Up to 49% energy savings (95% system peak efficiency)
Tough Wells High maintenance in heavy oil & sand Built for heavy oil, high-sand & high-viscosity fields
Control System Standalone variable-speed drive Dedicated SRD controller with HMI & soft start/stop
Downtime / Reliability Belt snaps & gearbox downtime risks 175,000+ logged hours with zero system downtime

BOREMAX

What Changes When You Switch

Simpler Drivetrain,
Lower Maintenance

  • No belts or gearboxes

  • No exposed pulleys or alignment issues

  • Direct-drive with fewer moving parts

Built for Tough
Wells

  • High-sand wells

  • High-viscosity & heavy oil fields

  • Continuous low-speed torque operation

Patented Backspin
Protection

  • 0.5s magnetic-powder brake response

  • PI-controlled backspin speed cap (≤ 20 RPM)

  • Backup supercapacitor energy for power loss

Dedicated Control &
Visibility

  • Speed accuracy to ±1 RPM

  • Rod-stick & anomaly auto-detection

  • Real-time HMI display & remote monitoring

Specification Parameter Value
Motor Type Switched Reluctance Direct Drive (Coaxial)
Rated Output Power 22 kW (11 kW / 37 kW available by special requirement)
Rated Voltage / Freq 380 / 420 / 440 / 460 / 480 V (50/60 Hz, ±15% range)
Rated Torque 1,050 N·m (Start / Overload capacity up to 200%)
Speed Range 20–200 RPM (±1 RPM speed accuracy)
Brake Response / Torque 0.5 seconds / 1,300 N·m combined braking capacity
Operating Temperature Down to -40°C Extreme Cold Ready (Alberta Special)
System Peak Efficiency 95% System Peak
Main Unit Dimensions 900 × 810 × 1,810 mm (35.5 × 31.9 × 71.3 in)
Control Cabinet Dimensions 960 × 800 × 1,980 mm (37.8 × 31.5 × 78.0 in)
Warranty 2-Year Warranty (2× standard PCP drive warranty)

BOREMAX

What Changes When You Switch

Simpler Drivetrain,
Lower Maintenance

  • No belts or gearboxes

  • No exposed pulleys or alignment issues

  • Direct-drive with fewer moving parts

Built for Tough
Wells

  • High-sand wells

  • High-viscosity & heavy oil fields

  • Continuous low-speed torque operation

Patented Backspin
Protection

  • 0.5s magnetic-powder brake response

  • PI-controlled backspin speed cap (≤ 20 RPM)

  • Backup supercapacitor energy for power loss

Dedicated Control &
Visibility

  • Speed accuracy to ±1 RPM

  • Rod-stick & anomaly auto-detection

  • Real-time HMI display & remote monitoring

Specification Parameter Value
Motor Type Switched Reluctance Direct Drive (Coaxial)
Rated Output Power 22 kW (11 kW / 37 kW available by special requirement)
Rated Voltage / Freq 380 / 420 / 440 / 460 / 480 V (50/60 Hz, ±15% range)
Rated Torque 1,050 N·m (Start / Overload capacity up to 200%)
Speed Range 20–200 RPM (±1 RPM speed accuracy)
Brake Response / Torque 0.5 seconds / 1,300 N·m combined braking capacity
Operating Temperature Down to -40°C Extreme Cold Ready (Alberta Special)
System Peak Efficiency 95% System Peak
Main Unit Dimensions 900 × 810 × 1,810 mm (35.5 × 31.9 × 71.3 in)
Control Cabinet Dimensions 960 × 800 × 1,980 mm (37.8 × 31.5 × 78.0 in)
Warranty 2-Year Warranty (2× standard PCP drive warranty)

Get in touch

U.S.-Based Operations,
Field-Proven Design

Boremax leases and supports its direct-drive systems for operators across the United States. The underlying technology is backed by a manufacturing facility in Douliu and an extensive field history across demanding international basins—including high-sand, heavy oil, and high-viscosity applications.

  • 14411 Catalina dr San Leandro CA 94576

Boremax provides direct-drive artificial lift systems engineered for reliable, efficient oil and gas production. Our lease-based solution helps operators reduce energy consumption, simplify field operations, and keep wells producing.
